Ballistic Separator

DCC Group Ballistic Separators are developed for efficient waste sorting. A ballistic separator, as the name indicates, is a high-load segregation device that separates different types of waste. It consists of parallel agitating paddles and a deck that oscillates at high speed to sort the waste stream passing through it.

Waste materials with similar shapes and sizes are separated into two or three fractions. For example, stones, C&D waste (Construction & Demolition waste), glass, and metals can be efficiently separated from reusable paper, plastic, cardboard, and other recyclable materials, along with RDF (Refuse Derived Fuel), while the remaining minus material is collected separately.

They can also sort fine particles, which can be collected independently using optional variable screen openings. In addition to being durable and precise, with advanced features that enhance performance, the Ballistic Separators or Bounce Screening from DCC Group are customized according to client requirements.

Types:

Ballistic separators are categorized based on the number of paddles, which determine the screening surface area and the flow of material processed through the separator.

4 Paddles:
The smallest type of ballistic separator. It is suitable for small plants or for improving collection efficiency when used in conjunction with an air separator.

8 Paddles:
An intermediate variant that can also be supplied with oversized paddles to increase the screening surface while maintaining the same number of paddles and only slightly increasing the overall dimensions. This system can perform multiple functions, from separating cardboard (> A4 size) to distinguishing between bottles (3D) and film (2D) in plastic streams.

12 Paddles:
A model developed to meet the requirements of waste sorting plants with high flow rates. Available with regular and oversized paddles, the oversized option provides an internal working diameter of 4300 mm and a screening surface of 24 m².

16 Paddles:
One of the largest ballistic separators in the world. It features an internal diameter of nearly 6 meters and a screening area of 32 m², suitable for systems with increasing flow rates (50+ t/h sorting lines).

ADVANTAGES

Fast production
Less wear & tear
Separated 3 Fractions of Material
Easy to maintain
Low power consumption
Low manpower requirement
Long-lasting bearing system
Easy and low maintenance
closed system for clean machine environment
Various modification choices e.g. angle of inclination, machine speed and screen plates
Low consumption of energy & self-cleaning brushes
Maintenance openings supported by gas springs allow convenient accessibility.

Should be used for Bigger size fraction & not less than 20mm size.
Ballistic separators are quite space consuming. Though we at DCC Ballistic separator ensure to make it customer friendly with easy availability at low cost but still these are quite non economical for low quantity waste processing system.

Eccentric Movement of Paddles
Separates Waste Into 3 Fractions
Lighter material which moves upwards due to eccentric motion supported by fan which mainly contains plastic papers, wrappers, cloth, papers etc.

Heavier/3D material – which is heavy in weight and slides down on the paddles to the bottom & get separated which mainly contains C&D waste, coconut shells, glass, metals, footwear & pet bottles

Minus material which screens down from the mesh paddling system, normally contains earth and other smaller size material

These machines can be used in both big and small plants based on the waste quantity and segregation capacity of the machines as they come in different variants and are highly adjustable and simple to install.

Ballistic Separator Waste Segregation Capacity: 10 TPH – 30 TPH

Waste Segregation Machine

Ballistic Separator machine - Zero Waste

Why:

DCC Group ballistic separator is the best choice at low cost and with good availability, for an efficient sorting operation.

Ballistic or Gravity separators from DCC Group are developed to separate biodegradable and non-biodegradable waste solids.
By adjusting the rotational speed, the conveying speed, the ballistic separation and the degree of material mixing can be modified.
A separation accuracy of 90% can be obtained.

An electrical gear motor powers the machine, making us one of the most reliable ballistic separator providers in India.

Let us take you through the other Importance of Ballistic separators in waste management that you can’t ignore.

Efficient Sorting Operation:

The Ballistic Separator Machine is the high load segregation device that segregates waste of different types based on their size and weight such as:

Construction & Demolition Waste (C&D)
Stones
Fibers
Wood
Glass
Metal
Rubber
Plastic
Paper
Containers
Cans
Cardboards
Other recyclable products

Most Common Advantages of Using Waste Segregation Machine

As Movable Ballistic Separator can be customized to meet the new-age requirements of the clients, it can offer you a plethora of advantages. And these are:

Fast and enormous output delivered diligently

No or less wear & tear
Convenient to use and handle
Low power consumption
Little or no manpower is needed
Very high uptimes
Addresses easy to complex customers challenges
Versatile in nature
Minimizes operational as well as maintenance costs
Flexible and less shifting time

Despite the size the shape of the materials, the Ballistic Separator working principle lies in the tremendous capability to sort out multiple operations with ease.

So, reach out to Ballistic Separator in India like us for the Sale. +91-7290049003

Get Quote For Ordering your next top-quality Ballistic Separator Machine!
